-50%
- Item Type: RC Drones
- Brand Name: Eachine Wizard X220HV
- Material: ABS, Plastic
| Item | Specification |
| X220HV Frame Kit | Wheel base: 220mmUpper plate thickness: 2.0mmFrame arm thickness: 5.0mmBottom plate thickness: 3.0mmX plate thickness: 1.5mmCamera side plate thickness: 1.5mmCamera standoffs: M3*28mm 1 PCFrame standoffs: M3*20mm 8 PCS |
| 2306 1650KV 3-6S Brushless Motor | Motor KV: 1650 RPM/V Idle current(Io/10V): 1.05ALipo cell: 3-6SWeight: 35gMax continuous current: 36AMax continuous power: 860WMax thrust: 2350gConfigu-ration: 12N/14PStator diameter: 23mmStator thickness: 6mmMotor diameter: 29mmMotor body length: 18.4mmOverall shaft length: 32.9mmProp adapter shaft: M5Bolt holes spacing: 16mmBolt thread: M3Propeller: 5-6 inch |
| 45A 4 In 1 BLHeli_S ESC 2-6S | Integrated PDBWorking voltage: 2-6S LipoContinuous working current: 4*45APeak current: 4*50A (6S)Main control chip: 48Mhz EFM8BB2Firmware: BLHeli_S Supports Dshot600MOS: 5*6 |
| Customized F4 Flight Controller Built-in OSD | Main control chip: STM32F405Sensor: MPU600 6 axesPower supply: 5VIntegrated OSDLC filter on boardSupports BetaFlight / inva running firmware |
| Foxeer Arrow Mini Pro 2.5mm 650TVL Camera | Solution: 1/3″ ForSony SUPER HAD II CCD + Nextchip 2040 DSPPixel: PAL: 976(H)x494(V)TV system: PALResolution: 600TVL(color) 650TVL(B&W)Synchronization: internalMin.illumination: 0.01LuxWDR: supportOSD programming board: supportWhite Dot repair: supportDNR: 2D DNRCamera title: supportImage adjustment: supportOSD: Edit name, power, flying timeInput power: 5-40VStorage temperature: -40℃~60℃Working temperature: -10℃~50℃Power consumption: 70mALow voltage alarm: supportPreset mode: DEF, VIVID, SUNNY, CLOUDY, LED TR, USR1Size: 21.8×21.8mmWeight: 8.7g(excluding bracket) |
| 5.8G 40CH 0mW/25mw/200mw/600mw VTX Switchable | Output power and transmission distance: ≥0.5km@25mW, ≥1km to 200mW, ≥2km to 600mWTransmission power: 0mW / 25mW / 200mW / 600mWFull video format: NTSC / PALInput voltage and power dissipation: 7V ~ 24V, + 12V / 260mA @ 600mWSize: 36*36*6mmWeight: ≤ 7g (excluding antenna)With output power self-check function.Nixie tube SCAN: frequency point (1-8), frequency band (AE), power (1-3, 0=0mw, 1=25mw, 2=200mw, 3=600mw) |
| SpeedyBee Bluetooth Module | Support Betaflight configuratorSpeedybee App: iOS 10.0+, iPad3; Androd 4.3+Output power: 0dBMSensitivity: -94dBMExternal interface: BROADCAST SWITCH, TX, RX, 3-5V DC Input, GNDTransmission speed: Bidirectional 1K/SBluetooth protocol: Bluetooth Specification V4.0 BLETransmission distance: 30 metersFrequency range: 2400MHz-2483.5MHz (2.4G ISM Band)Baud rate: 2400, 4800, 9600, 14400, 19200(default), 28800, 38400, 57600, 76800, 115200, 230400Working voltage: 3.3V-5.0VWorking current: 8.3mA-10mAWeight: 1.4gSize: 27*15*4.5mm |
| 110DB BB Alarm Buzzer | Working voltage: 5VStandby battery: lipo 4.2V 100mahLoudness: 110DBSize: 36 * 36mmWeight: 8g |
| Dalprop Cyclone T5046C propeller | Size: 5046 5×4.6Mounting hole: 5mmColor: transparent purple & transparent whiteQuantity: 4 pairs (2 pairs of transparent purple + 2 pairs of transparent white) |
| Lipo Battery | Not includedRecommend 4-6S 1500mah-1800mah |
Package Includes:
- 1 x X220HV frame kit
- 2 x 2306 1650KV brushless motor CW
- 2 x 2306 1650KV brushless motor CCW
- 1 x 4 IN 1 45A BLHeli_S ESC
- 1 x Customized F4 flight controller Built-in OSD
- 1 x Foxeer arrow mini pro 2.5mm 650TVL camera
- 1 x 5.8G 40CH 0mW/25mw/200mw/600mw VTX Switchable
- 1 x 110DB BB alarm buzzer
- 1 x SpeedyBee bluetooth module
- 1 x 45mm RP-SMA male antenna RHCP
- 2 x 200*20mm battery strap
- 1 x 30° camera mount compatible with Runcam 3 3S Gopro session
- 2 x Dalprop cyclone T5046C transparent white CW
- 2 x Dalprop cyclone T5046C transparent white CCW
- 2 x Dalprop cyclone T5046C transparent purple CW
- 2 x Dalprop cyclone T5046C transparent purple CCW
- 10 x 2.5*100mm nylon strap black
